If you are here for the first time (or come back frequently), there’s a new Row Level Security page (up in the top toolbar) which gives an overview of your options in Tableau and links to the individual blog posts that dive into detail. Recommended reading for everyone, and it will be kept up to date over time with any changes or additions to functionality.
Web sites have to work on an incredibly wide variety of displays these days. The work to make a single page look as good as possible on all those displays often falls under the heading of “Responsive Design”.
When embedding a Tableau viz into another application, the actual “view area” for the Tableau viz is just one component of a page. In this situation, the view we pick from Tableau really needs to fill the most space of the area it has been allotted on the page. So let’s think a little more deeply about proportions and how we can best fit our embedded vizes given the tools available, and how to tie them all together to give the best possible experience to the end user, with the least effort for our Tableau viz designers.
Tableau recognizes the need for Responsive Design with a feature called Device Designer. It allows you to specify three different layouts, which are called in the system Desktop, Tablet, and Phone. These map well to the situations where you are looking at Tableau Server directly or in the Tableau phone app, and the Tableau viz is assumed to take the full width of the viewing area (and often most of the height). If different layouts exist, Tableau Server will automatically pick a layout based on the view space dimensions it detects.
However, when a Tableau viz is embedded into another page, it lives in a regular HTML div which can be styled using CSS3 and changed dynamically using JavaScript. Web designers regularly use these features to make page elements respond to changes in the viewing area (hence Responsive Design). Modern web browsers can actually scale up or down whatever is in a div without needing the content of the div to change.
Given all these capabilities, what is the best way to get our Tableau content to look its best in a page, regardless of the size or device it loads on?
Now let’s dig into how to make all of this happen.
(more…)This post outlines a bittersweet event: the release of tableau_tools 6, which will also be the final release of the library by me, the original author of the library. My time at Tableau has come to an end, but ownership of this blog and all of the various code will remain with Tableau. As the project has always been open-source under a permissive license, this just means that there won’t be any updates from me, but the project can continue as long as it proves useful to someone.
As always, you can install or upgrade tableau_tools from PyPi.org via pip:
pip install tableau_tools --upgradeNote: Version 6.0.0 does break some backward compatibility (see below) and you may need to do some slight updates to code that used a 5.0.0 release, or a lot if you are still using 4.0.0.
It’s 2021 (thankfully!), and you are reading this, and probably thinking – why are there multiple libraries for working with the Tableau REST API. It’s a long story, but in essence much of tableau_tools and the content on this blog covering it was written before the Tableau Server Client (TSC) library either existed or was mature enough to cover certain use cases. There is also the tableau-api-lib which is a newer implementation along the original lines of what tableau_tools started out as, and it seems fine for getting work done, but doesn’t seem to have some of the abstraction layers of tableau_tools.
All of the libraries are fit for a wide number of purposes. tableau_tools is distinguished by having two main packages:
There was a time where tableau_rest_api referenced some of the tableau_documents capabilities, but there are no longer any supported versions of Tableau Server where those techniques were necessary, so either component can be used by itself.
If you have any of these needs in your project, then it is worth considering tableau_tools for at least some of the implementation. Otherwise, you should go with the TSC as it is more widely used, available, and supported within Tableau and the partner network.
(more…)Even though Tableau Server stores the “full names” of published Workbooks, Datasources and Worksheets in Unicode exactly as published, the algorithm used to create the “contentUrl” used in the URL to reference the published content is based only on the ASCII English characters. The algorithm completely drops any non-ASCII character (and a few other non-URL safe characters). If any other existing contentUrl is found, an underscore and numeral is appended at the end.
In European languages with an expanded character set beyond the ASCII characters, the algorithm results in reduced but still distinctive contentUrls. For example (in Spanish): “Años” -> “Aos”. The risk here, depending on language, is that there may be distinct content names that are reduced to the same contentUrl, resulting in the appending of the numeral to distinguish them like: “Aos” vs. “Aos_1”.
In Chinese, Korean and Japanese (and any other fully non-Latin character sets), the names are reduced to nothing, and then a random number is assigned: “销售运营分析仪表板”-> “_0” or “_1”.
Editor’s Note: Huge thanks to Robin Cottiss who helped me navigate the world of authentication in Tableau as he has for so many years to be able to write this. He doesn’t have the same online presence as a lot of other Tableau wizards but I can’t say how much of my and others Tableau knowledge that is out there has either been guided by or just a straight repackaging of the hard-gained work Robin has put in.
When embedding Tableau vizes for external use, the three most common SSO mechanisms are Trusted Authentication, SAML, and OpenID Connect (OIDC).
Trusted Authentication or Trusted Tickets has two modes, which are set as server-level flags:
SAML and OpenID Connect always create a full session, so they work like Unrestricted Tickets.
Additionally, Restricted Trusted Tickets (the default Trusted Authentication mode) also disables:
Many customers would prefer to have a session started with any of the three SSO mechanisms, that allows all the Viz features, but doesn’t let the user ever get to the full Tableau Server UI. Is it possible?
(more…)There’s a great Whitepaper which really goes in depth on how to configure Tableau for Row Level Security, but sometimes it’s nice to have a quick overview that cuts right to the chase. Over a lot of years of explaining how it works, I hope this will outline the standard way of implementing RLS in Tableau in a way that helps you get results as quickly as possible.
Row Level Security is the process of securely filtering data down so a user only see what they should once they are looking at a data source. You could call it “User Data Filtering” just as easily. In essence, you are limiting the returned rows – hence “row level security”.
(more…)One of the great advantages of tsm is that it is a fully functioning shell / command-line system that works the same on Linux or Windows. Finding the commands to do what you want to do in Tableau – that’s the easy part these days. But both Windows and Linux have their own quirks, especially when you want to fully automate a process. This post discusses how to get things working on Linux – if you need to automate on Windows, take a look here.
Shell scripting on Linux, particularly when you want to schedule using cron, have a lot more quirks than you’d think at first glance. It’s very common for the same set of commands you just typed in to not work at all when you put them in a shell script. And even then it may still fall over when run via cron. To run tsm commands from a script, we have to make sure our environment is always specified correctly.
(more…)This question was brought by my fantastisch colleague Timo Tautenhahn, who runs tableaufans.com. He was seeing some performance issues with using the Refresh commands in the JS and Extensions API, but not encountering the issues when changing a filter, which also was causing a new query to the database
In essence, whatever happens when the Refresh command fires off involves more steps than just re-querying. So the question is: what can force a re-query without the Refresh commands?
You can have your own fun coming up with logical statements that are always true, but you don’t need anything more complex than:
SELECT * FROM table t WHERE [Tableau Parameter] = [Tableau Parameter]As long as you change the value of the parameter to something you haven’t used yet within the session, each change should force a query refresh without using the Refresh action. Simply incrementing up from zero is enough to make it work.
(more…)Given all the updates to Tableau Online over the last few years, now seems like as good of time as any to review over when Tableau Online works for embedding Tableau.
What do I mean by embedding in this case? Specifically, to display Tableau visualizations in another web application, without the customer being aware of Tableau Online as a separate entity from the rest of the web application.
Tableau has the most flexibility for doing Row Level Security filtering using what is termed the “Standard Method”: a JOIN between a Data Table and an Entitlements table. The basic assumption, as seen in the RLS Whitepaper, is that this Entitlements table exists in the same database at the Data Table. This is a very narrow assumption, that is only true for a small subset of real deployments.
In many environments and applications, there is no “Entitlements” table within the same logical database as the Data table. In fact, there may be no “Entitlements table” that can be reached at all — entitlements can be retrieved somehow, but they may be in any number of forms.
The most common request I see is to pass a set of Attributes (lists or arrays) of values directly into a Tableau report at run-time. The rest of the post will describe a flexible and generic method for making this possible in a secure way. It builds upon the baseline of the PostgreSQL/Python environment in the using a Web Service as a Data Source post, but is even simpler.
For a variety of reasons, Trusted Authentication / Trusted Tickets is often the best choice for SSO into a Tableau Server. Trusted Authentication actually establishes a Tableau Session in the browser, so you can use it once to establish SSO for a whole browser session.
In this post, I’ll describe a best practice method for implementing the Session-Level Sign-O and provide a small JavaScript file with actual implementation of all the concepts.
You can find the auth_helpers.js file on GitHub with all the code necessary for this process (except for the back-end Trusted Tickets request, which you need to build in your own web application environment).
